Sinnor Instruments, Inc.

8 inch TFT screen:
High resolution: 800×600dpi
Standard 6 parameters:
ECG, SpO2, NIBP, TEMP, RESP, HR/PR
Optional parameters:
Touch screen, 2-IBP, EtCO2, Printer, etc.
Patient Range:
Adult, Pediatric,

Features &Benefits:

1.   8” color TFT display, high resolution 800×600 dpi;

2.  Separated para board: ECG, NIBP, SpO2 board;

3.  Full touch-screen enables intuitive operation by clicking one the specific parameters or the waveform in real time, standard configuration includes the navigation knob.

4.  Real time S-T segment analysis, and ARR analysis;

5.  SpO2 Pitch Tone Variation and Drug Dose Calculation;

6.  Parameter waveform and characters color selectable

7.  Multi and unique display: Standard, Large font, Trend Coexis, OxyCRG dynamic

8.  Standby mode for Energy saving and suspend monitoring;

9.  7-lead ECG waveforms display in phase;

10. Capture dynamic waveforms;

11. Built-in rechargeable lithium battery, and battery volume checking.

12.  Efficient resistance to interference of defibrillator and HF knife;

13.  SINNOR F-6 SpO2 technology, VS NELLCOR accuracy;

14.  TCP/IP networking platform enable abundant future upgrade

15.   Complete and flexible mounting solution for transportation and in-patient monitoring

Standard parameters: 5-lead ECG, RESP, HR, NIBP, SPO2(F-5), 1-TEMP, PR;

Optional: Touch Screen, Thermal Recorder, 3/12- lead ECG,SD card,

2/ 4-IBP,EtCO2, SpO2(F-6)
